Download Sheet METALU 3000
Technical characteristics: Aisi 316 lacquered stainless steel device with electric mechanism (24V battery.) Approved for lifting 120kg. Consisting of: Base platform to anchor to the ground, mast with pivoting arm. Vertical prism Electric mechanism: Electric actuator 24V. Control box. Hand button panel. 2 batteries. Battery charger. Protection I P 65 Operated from hand control panel. Removable seat. Armrest. Vertical seat travel: 1.2m (depending on the wall to be freed). (depending on the wall to be cleared) Weight 45 Kgs. Approx.
